Description
GENERAL SPECIFICATIONS
Function: Cooling/Heating
Capacity Btu/h: Cooling 18083.6/21496 + Heating 0/23884
PDESIGNC/PDESIGNH (AVG): Kw 5.3/4.2
SEER/SCOP: 7.3/5.7
Energy Class Cool/Heat(W)Heat(C): A++/A+++
Power Supply: 1Ph,220-240V,50Hz
Power Input W: Cooling 1501 / Heating 1393
Current (A): Cooling 7.2 / Heating 6.3
Airflow Volume m³/h: 1000/850/760/650/580/520/450
FEATURES
Features: Inverter Technology, Intelligent Defrosting, Comfortable Sleep Curves, Cold Air Prevention, Timer, Turbo Button, Self-Diagnosis, Auto Clean (X-Fan), Dehumidifier, Intelligent Auto, Auto Restart, Cold Plasma Filter, Wifi, 5W Stand By, Led Display, Refrigerant R-32.
INDOOR UNIT
Sound Pressure Level dB(A) (H/M/L): 45/42/41/37/34/29/26
Outline Dimension W/H/D: 982x311x221 mm
OUTDOOR UNIT
Sound Pressure Level dB(A): 56
Piping Connection (inch): Gas 3/8 + Liquid 1/4
Outline Dimension W/H/D: 802x555x350 mm
